Help for package TreeBUGS

Version:

1.5.0

Date:

2023-05-21

Title:

Hierarchical Multinomial Processing Tree Modeling

Maintainer:

Daniel W. Heck <daniel.heck@uni-marburg.de>

Depends:

R (≥ 4.0.0)

Imports:

Rcpp (≥ 0.12.6), runjags, stats, graphics, utils, grDevices, coda, parallel, rjags, MASS, hypergeo, logspline

Suggests:

knitr, rmarkdown, testthat, R.rsp

LinkingTo:

Rcpp, RcppArmadillo

VignetteBuilder:

knitr, R.rsp

NeedsCompilation:

yes

SystemRequirements:

JAGS (https://mcmc-jags.sourceforge.io/)

Description:

User-friendly analysis of hierarchical multinomial processing tree (MPT) models that are often used in cognitive psychology. Implements the latent-trait MPT approach (Klauer, 2010) <doi:10.1007/s11336-009-9141-0> and the beta-MPT approach (Smith & Batchelder, 2010) <doi:10.1016/j.jmp.2009.06.007> to model heterogeneity of participants. MPT models are conveniently specified by an .eqn-file as used by other MPT software and data are provided by a .csv-file or directly in R. Models are either fitted by calling JAGS or by an MPT-tailored Gibbs sampler in C++ (only for nonhierarchical and beta MPT models). Provides tests of heterogeneity and MPT-tailored summaries and plotting functions. A detailed documentation is available in Heck, Arnold, & Arnold (2018) <doi:10.3758/s13428-017-0869-7> and a tutorial on MPT modeling can be found in Schmidt, Erdfelder, & Heck (2022) <doi:10.31234/osf.io/gh8md>.

License:

GPL-3

Encoding:

UTF-8

URL:

https://github.com/danheck/TreeBUGS

RoxygenNote:

7.2.3

LazyData:

TRUE

Packaged:

2023-05-21 15:13:41 UTC; daniel

Author:

Daniel W. Heck

[aut, cre], Nina R. Arnold [aut, dtc], Denis Arnold [aut], Alexander Ly [ctb], Marius Barth

[ctb]

Repository:

CRAN

Date/Publication:

2023-05-21 22:40:02 UTC

TreeBUGS: Hierarchical Multinomial Processing Tree Modeling

Description

logo

Uses standard MPT files in the .eqn-format (Moshagen, 2010) to fit hierarchical Bayesian MPT models. Note that the software JAGS is required (https://mcmc-jags.sourceforge.io/).

The core functions either fit a Beta-MPT model (betaMPT; Smith & Batchelder, 2010) or a latent-trait MPT model (traitMPT; Klauer, 2010). A fitted model can be inspected using convenient summary and plot functions tailored to hierarchical MPT models.

Detailed explanations and examples can be found in the package vignette, accessible via vignette("TreeBUGS")

Citation

If you use TreeBUGS, please cite the software as follows:

Heck, D. W., Arnold, N. R., & Arnold, D. (2018). TreeBUGS: An R package for hierarchical multinomial-processing-tree modeling. Behavior Research Methods, 50, 264–284. doi:10.3758/s13428-017-0869-7

Tutorial

For a tutorial on MPT modeling (including hierarchical modeling in TreeBUGS), see:

Schmidt, O., Erdfelder, E., & Heck, D. W. (2022). Tutorial on multinomial processing tree modeling: How to develop, test, and extend MPT models. https://psyarxiv.com/gh8md/

Author(s)

Daniel W. Heck, Denis Arnold, & Nina Arnold

References

Klauer, K. C. (2010). Hierarchical multinomial processing tree models: A latent-trait approach. Psychometrika, 75, 70-98. doi:10.1007/s11336-009-9141-0

Matzke, D., Dolan, C. V., Batchelder, W. H., & Wagenmakers, E.-J. (2015). Bayesian estimation of multinomial processing tree models with heterogeneity in participants and items. Psychometrika, 80, 205-235. doi:10.1007/s11336-013-9374-9

Moshagen, M. (2010). multiTree: A computer program for the analysis of multinomial processing tree models. Behavior Research Methods, 42, 42-54. doi:10.3758/BRM.42.1.42

Smith, J. B., & Batchelder, W. H. (2008). Assessing individual differences in categorical data. Psychonomic Bulletin & Review, 15, 713-731. doi:10.3758/PBR.15.4.713

Smith, J. B., & Batchelder, W. H. (2010). Beta-MPT: Multinomial processing tree models for addressing individual differences. Journal of Mathematical Psychology, 54, 167-183. doi:10.1016/j.jmp.2009.06.007

Bayes Factors for Simple (Nonhierarchical) MPT Models

Description

Computes Bayes factors for simple (fixed-effects, nonhierarchical) MPT models with beta distributions as priors on the parameters.

Usage

BayesFactorMPT(
  models,
  dataset = 1,
  resample,
  batches = 5,
  scale = 1,
  store = FALSE,
  cores = 1
)

Arguments

models

list of models fitted with simpleMPT, e.g., list(mod1, mod2)

dataset

for which data set should Bayes factors be computed?

resample

how many of the posterior samples of the MPT parameters should be resampled per model

batches

number of batches. Used to compute a standard error of the estimate.

scale

how much should posterior-beta approximations be downscaled to get fatter importance-sampling density

store

whether to save parameter samples

cores

number of CPUs used

Details

Currently, this is only implemented for a single data set!

Uses a Rao-Blackwellized version of the product-space method (Carlin & Chib, 1995) as proposed by Barker and Link (2013). First, posterior distributions of the MPT parameters are approximated by independent beta distributions. Second, for one a selected model, parameters are sampled from these proposal distributions. Third, the conditional probabilities to switch to a different model are computed and stored. Finally, the eigenvector with eigenvalue one of the matrix of switching probabilities provides an estimate of the posterior model probabilities.

References

Barker, R. J., & Link, W. A. (2013). Bayesian multimodel inference by RJMCMC: A Gibbs sampling approach. The American Statistician, 67(3), 150-156.

Carlin, B. P., & Chib, S. (1995). Bayesian model choice via Markov chain Monte Carlo methods. Journal of the Royal Statistical Society. Series B (Methodological), 57(3), 473-484.

Bayes Factor for Slope Parameters in Latent-Trait MPT

Description

Uses the Savage-Dickey method to compute the Bayes factor that the slope parameter of a continuous covariate in traitMPT is zero vs. positive/negative/unequal to zero.

Usage

BayesFactorSlope(
  fittedModel,
  parameter,
  direction = "!=",
  approx = "normal",
  plot = TRUE,
  ...
)

Arguments

fittedModel

a fitted latent-trait model fitted with traitMPT with predictor variables that have been defined via predStructure.

parameter

name of the slope parameter (e.g., "slope_d_covariate").

direction

alternative hypothesis: whether slope is smaller or larger than zero ("<" or ">") or unequal to zero ("!=").

approx

how to approximate the posterior density of the slope parameter at zero: approx="normal" uses a normal approximation to all samples and approx="logspline" uses a nonparametric density estimate of the package logspline. Usually, both methods provide similar results.

plot

if TRUE, the prior and posterior densities and the ratio at slope=0 are plotted.

...

further arguments passed to logspline, which is used to approximate the density of the posterior distribution.

Details

The Bayes factor is computed with the Savage-Dickey method, which is defined as the ratio of the density of the posterior and the density of the prior evaluated at slope=0 (Heck, 2019). Note that this method cannot be used with default JZS priors (IVprec="dgamma(.5,.5)") if more than one predictor is added for an MPT parameter. As a remedy, a g-prior (normal distribution) can be used on the slopes by setting the hyperprior parameter g to a fixed constant when fitting the model: traitMPT(..., IVprec = 1) (see Heck, 2019).

References

Heck, D. W. (2019). A caveat on the Savage-Dickey density ratio: The case of computing Bayes factors for regression parameters. British Journal of Mathematical and Statistical Psychology, 72, 316–333. doi:10.1111/bmsp.12150

Examples

## Not run:
# latent-trait MPT model for the encoding condition (see ?arnold2013):
EQNfile <- system.file("MPTmodels/2htsm.eqn", package = "TreeBUGS")
d.enc <- subset(arnold2013, group == "encoding")

fit <- traitMPT(EQNfile,
  data = d.enc[, -(1:4)], n.thin = 5,
  restrictions = list("D1=D2=D3", "d1=d2", "a=g"),
  covData = d.enc[, c("age", "pc")],
  predStructure = list("D1 ; age")
)
plot(fit, parameter = "slope", type = "default")
summary(fit)

BayesFactorSlope(fit, "slope_D1_age", direction = "<")

## End(Not run)

Compute Posterior Predictive P-Values

Description

Computes posterior predictive p-values to test model fit.

Usage

PPP(fittedModel, M = 1000, nCPU = 4, T2 = TRUE, type = "X2")

Arguments

fittedModel

fitted latent-trait or beta MPT model (traitMPT, betaMPT)

M

number of posterior predictive samples. As a maximum, the number of posterior samples in fittedModel is used.

nCPU

number of CPUs used for parallel sampling. For large models and many participants, this requires considerable computer-memory resources (as a remedy, use nCPU=1).

T2

whether to compute T2 statistic to check coveriance structure (can take a lot of time). If some participants do not have responses for some trees, (co)variances are computed by pairwise deletion of the corresponding persons.

type

whether the T1 statistic of expected means is computed using Person's "X2" or the likelihood-ratio statistic "G2"

Author(s)

Daniel Heck

References

Klauer, K. C. (2010). Hierarchical multinomial processing tree models: A latent-trait approach. Psychometrika, 75, 70-98.

WAIC: Widely Applicable Information Criterion

Description

Implementation of the WAIC for model comparison.

Usage

WAIC(
  fittedModel,
  n.adapt = 1000,
  n.chains = 3,
  n.iter = 10000,
  n.thin = 1,
  summarize = FALSE
)

## S3 method for class 'waic'
print(x, ...)

## S3 method for class 'waic_difference'
print(x, ...)

## S3 method for class 'waic'
e1 - e2

Arguments

fittedModel

fitted latent-trait or beta MPT model (traitMPT, betaMPT)

n.adapt

number of adaptation samples.

n.chains

number of chains (no parallel computation).

n.iter

number of iterations after burnin.

n.thin

Thinning rate.

summarize

deprecated argument only available for backwards compatibility

x

An object of class waic or waic_difference to be printed.

...

Further arguments that may be passed to print methods.

e1, e2

Two objects of class waic to be compared.

Details

WAIC provides an approximation of predictive accuracy with respect to out-of-sample deviance. The uncertainty of the WAIC for the given number of observed nodes (i.e., number of free categories times the number of participants) is quantified by the standard error of WAIC "se_waic" (cf. Vehtari et al., 2017). In contrast, to assess whether the approximation uncertainty due to MCMC sampling (not sample size) is sufficiently low, it is a good idea to fit each model twice and compute WAIC again to assess the stability of the WAIC values.

For more details, see Vehtari et al. (2017) and the following discussion about the JAGS implementation (which is currently an experimental feature of JAGS 4.3.0):

https://sourceforge.net/p/mcmc-jags/discussion/610036/thread/8211df61/

Value

Function WAIC() returns an object of class waic, which is basically a list containing three vectors p_waic, deviance, and waic, with separate values for each observed node (i.e., for all combinations of persons and free categories).

For these objects, a print() method exists, which also calculates the standard error of the estimate of WAIC.

For backwards compatibility, if WAIC() is called with summarize = TRUE, a vector with values p_waic, deviance, waic, and se_waic is returned.

WAIC values from two models can be compared by using the - operator; the result is an object of class waic_difference.

References

Vehtari, A., Gelman, A., & Gabry, J. (2017). Practical Bayesian model evaluation using leave-one-out cross-validation and WAIC. Statistics and Computing, 27(5), 1413–1432. doi:10.1007/s11222-016-9696-4

Examples

## Not run:

#### WAIC for a latent-trait MPT model:
fit <- traitMPT(...)
WAIC(fit)


#### pairwise comparison of two models:

# (1) compute WAIC per model
waic1 <- WAIC(fit1)
waic2 <- WAIC(fit2)

# (2) WAIC difference
waic1 - waic2

## End(Not run)

Data of a Source-Monitoring Experiment

Description

Dataset of a source-monitoring experiment by Arnold, Bayen, Kuhlmann, and Vaterrodt (2013) using a 2 (Source; within) x 3 (Expectancy; within) x 2 (Time of Schema Activation; between) mixed factorial design.

Usage

arnold2013

Format

A data frame 13 variables:

subject: Participant code
age: Age in years
group: Between-subject factor "Time of Schema Activation": Retrieval vs. encoding condition
pc: perceived contingency
EE: Frequency of "Source E" responses to items from source "E"
EU: Frequency of "Source U" responses to items from source "E"
EN: Frequency of "New" responses to items from source "E"
UE: Frequency of "Source E" responses to items from source "E"
UU: Frequency of "Source U" responses to items from source "E"
UN: Frequency of "New" responses to items from source "E"
NE: Frequency of "Source E" responses to new items
NU: Frequency of "Source U" responses to new items
NN: Frequency of "New" responses to new items

Details

Eighty-four participants had to learn statements that were either presented by a doctor or a lawyer (Source) and were either typical for doctors, typical for lawyers, or neutral (Expectancy). These two types of statements were completely crossed in a balanced way, resulting in a true contingency of zero between Source and Expectancy. Whereas the profession schemata were activated at the time of encoding for half of the participants (encoding condition), the other half were told about the profession of the sources just before the test (retrieval condition). After the test, participants were asked to judge the contingency between item type and source (perceived contingency pc).

References

Arnold, N. R., Bayen, U. J., Kuhlmann, B. G., & Vaterrodt, B. (2013). Hierarchical modeling of contingency-based source monitoring: A test of the probability-matching account. Psychonomic Bulletin & Review, 20, 326-333.

Examples

head(arnold2013)

## Not run:
# fit hierarchical MPT model for encoding condition:
EQNfile <- system.file("MPTmodels/2htsm.eqn", package = "TreeBUGS")
d.encoding <- subset(arnold2013, group == "encoding", select = -(1:4))
fit <- betaMPTcpp(EQNfile, d.encoding,
  n.thin = 5,
  restrictions = list("D1=D2=D3", "d1=d2", "a=g")
)
# convergence
plot(fit, parameter = "mean", type = "default")
summary(fit)

## End(Not run)

Fit a Hierarchical Beta-MPT Model

Description

Fits a Beta-MPT model (Smith & Batchelder, 2010) based on a standard MPT model file (.eqn) and individual data table (.csv).

Usage

betaMPT(
  eqnfile,
  data,
  restrictions,
  covData,
  transformedParameters,
  corProbit = FALSE,
  alpha = "dgamma(1, 0.1)T(1,)",
  beta = "dgamma(1, 0.1)T(1,)",
  n.iter = 20000,
  n.adapt = 2000,
  n.burnin = 2000,
  n.thin = 5,
  n.chains = 3,
  dic = FALSE,
  ppp = 0,
  monitorIndividual = TRUE,
  modelfilename,
  parEstFile,
  posteriorFile,
  autojags = NULL,
  ...
)

Arguments

eqnfile

The (relative or full) path to the file that specifies the MPT model (standard .eqn syntax). Note that category labels must start with a letter (different to multiTree) and match the column names of data. Alternatively, the EQN-equations can be provided within R as a character value (cf. readEQN). Note that the first line of an .eqn-file is reserved for comments and always ignored.

data

The (relative or full) path to the .csv file with the data (comma separated; category labels in first row). Alternatively: a data frame or matrix (rows=individuals, columns = individual category frequencies, category labels as column names)

restrictions

Specifies which parameters should be (a) constant (e.g., "a=b=.5") or (b) constrained to be identical (e.g., "Do=Dn") or (c) treated as fixed effects (i.e., identical for all participants; "a=b=FE"). Either given as the path to a text file with restrictions per row or as a list of restrictions, e.g., list("D1=D2","g=0.5"). Note that numbers in .eqn-equations (e.g., d*(1-g)*.50) are directly interpreted as equality constraints.

covData

Data that contains covariates, for which correlations with individual MPT parameters will be sampled. Either the path to a .csv file (comma-separated: rows=individuals in the same order as data; first row must contain covariate labels). Alternatively: a data frame or matrix (rows=individuals, columns = variables; covariate labels as column names). Note that in betaMPT, correlations are computed for discrete variables that are coded numerically (in traitMPT, this can be suppressed by using predType="f")

transformedParameters

list with parameter transformations that should be computed based on the posterior samples of the group-level means (e.g., for testing parameter differences: list("diffD=Do-Dn")), or path to a text file containing one transformation per line. Transformations of individual-level parameters can also be performed after fitting a model using transformedParameters.

corProbit

whether to use probit-transformed MPT parameters to compute correlations (probit-values of +Inf are truncated to max(5,max(probit)); similarly for -Inf). Default for beta-MPT: MPT parameters are used on the probability scale [0,1].

alpha

Hyperprior for the shape parameters \alpha of the group-level beta distributions (in JAGS syntax). Default: Truncated gamma distributions for \alpha and \beta with shape 1 and rate 0.1 and truncated to be larger than 1 (see plotPrior). A named vector can be used to specify separate hyperpriors for each MPT parameter (if unnamed, the order of parameters is determined by the default order as shown by readEQN with paramOrder = TRUE). Originally, Smith and Batchelder (2008) used the "WinBUGS-zeros-trick" (available in TreeBUGS if alpha="zero" or beta="zero"), which approximates uniform priors on the group-level mean and SD (but often results convergence issues).

beta

Hyperprior for \beta of group-level distributions, see alpha.

n.iter

Number of iterations per chain (including burnin samples). See run.jags for details.

n.adapt

number of adaption samples to adjust MCMC sampler in JAGS. The sampler will be more efficient if it is tuned well. However, MCMC sampling will still give correct results even if the warning appears: "Adaptation incomplete." (this just means that sampling efficiency could be better).

n.burnin

Number of samples for burnin (samples will not be stored and removed from n.iter)

n.thin

Thinning rate.

n.chains

number of MCMC chains (sampled in parallel).

dic

whether to compute DIC using extract.runjags, which requires additional sampling. Can also be computed and added after fitting the model by fittedModel$summary$dic <- runjags::extract(fittedModel$runjags, "dic"). As an alternative information criterion, WAIC can be computed for fitted models.

ppp

number of samples to compute posterior predictive p-value (see posteriorPredictive)

monitorIndividual

whether to store MCMC samples of the MPT parameters theta at the individual level (i.e., the random effects). If FALSE, it is not possible to perform posterior-predictive checks.

modelfilename

name of the generated JAGS model file. Default is to write this information to the tempdir as required by CRAN standards.

parEstFile

Name of the file to with the estimates should be stored (e.g., "parEstFile.txt")

posteriorFile

path to RData-file where to save the model including MCMC posterior samples (an object named fittedModel; e.g., posteriorFile="mcmc.RData")

autojags

JAGS first fits the MPT model as usual and then draws MCMC samples repeatedly until convergence. For this, the function autoextend.jags is used with the arguments provided in autojags (this can be an empty list, in which case the defaults are used). Possible arguments for autoextend.jags are: list(startburnin = 1000, startsample = 5000, adapt = 2000, max.time="30m") (the last of these arguments restricts sampling to 30 minutes, see autoextend.jags).

...

further arguments to be passed to the JAGS sampling function (i.e., to run.jags. Note that reproducible results are obtained by setting a random seed before fitting a model (i.e., set.seed(12345) ).

Details

Note that, in the Beta-MPT model, correlations of individual MPT parameters with covariates are sampled. Hence, the covariates do not affect the estimation of the actual Beta-MPT parameters. Therefore, the correlation of covariates with the individual MPT parameters can equivalently be performed after fitting the model using the sampled posterior parameter values stored in betaMPT$mcmc

Value

a list of the class betaMPT with the objects:

summary: MPT tailored summary. Use summary(fittedModel)
mptInfo: info about MPT model (eqn and data file etc.)
runjags: the object returned from the MCMC sampler. Note that the object fittedModel$runjags is an runjags object, whereas fittedModel$runjags$mcmc is a mcmc.list as used by the coda package (mcmc)

Author(s)

Daniel W. Heck, Nina R. Arnold, Denis Arnold

References

Examples

## Not run:
# fit beta-MPT model for encoding condition (see ?arnold2013):
EQNfile <- system.file("MPTmodels/2htsm.eqn", package = "TreeBUGS")
d.encoding <- subset(arnold2013, group == "encoding", select = -(1:4))
fit <- betaMPT(EQNfile, d.encoding,
  n.thin = 5,
  restrictions = list("D1=D2=D3", "d1=d2", "a=g")
)
# convergence
plot(fit, parameter = "mean", type = "default")
summary(fit)

## End(Not run)

C++ Sampler for Hierarchical Beta-MPT Model

Description

Fast Gibbs sampler in C++ that is tailored to the beta-MPT model.

Usage

betaMPTcpp(
  eqnfile,
  data,
  restrictions,
  covData,
  corProbit = FALSE,
  n.iter = 20000,
  n.burnin = 2000,
  n.thin = 5,
  n.chains = 3,
  ppp = 0,
  shape = 1,
  rate = 0.1,
  parEstFile,
  posteriorFile,
  cores = 1
)

Arguments

eqnfile

data

restrictions

covData

corProbit

n.iter

Number of iterations per chain (including burnin samples). See run.jags for details.

n.burnin

Number of samples for burnin (samples will not be stored and removed from n.iter)

n.thin

Thinning rate.

n.chains

number of MCMC chains (sampled in parallel).

ppp

number of samples to compute posterior predictive p-value (see posteriorPredictive)

shape

shape parameter(s) of Gamma-hyperdistribution for the hierarchical beta-parameters \alpha_s and \beta_s (can be a named vector to provide different hyperpriors for each parameter)

rate

rate parameter(s) of Gamma-hyperdistribution

parEstFile

Name of the file to with the estimates should be stored (e.g., "parEstFile.txt")

posteriorFile

path to RData-file where to save the model including MCMC posterior samples (an object named fittedModel; e.g., posteriorFile="mcmc.RData")

cores

number of CPUs to be used

Author(s)

Daniel Heck

Examples

## Not run:
# fit beta-MPT model for encoding condition (see ?arnold2013):
EQNfile <- system.file("MPTmodels/2htsm.eqn", package = "TreeBUGS")
d.encoding <- subset(arnold2013, group == "encoding", select = -(1:4))
fit <- betaMPTcpp(EQNfile, d.encoding,
  n.thin = 5,
  restrictions = list("D1=D2=D3", "d1=d2", "a=g")
)
# convergence
plot(fit, parameter = "mean", type = "default")
summary(fit)

## End(Not run)

Between-Subject Comparison of Parameters

Description

Computes differencesor other statistics of MPT parameters for two hierarchical MPT models fitted separately to between-subjects data

Usage

betweenSubjectMPT(
  model1,
  model2,
  par1,
  par2 = par1,
  stat = c("x-y", "x<y"),
  plot = FALSE
)

Arguments

model1

fitted hierarchical MPT model for first between-subjects condition

model2

fitted hierarchical MPT model for second between-subjects condition

par1

label of parameter from first model for which statistic should be computed

par2

label of parameter from second model. Default: The same parameter as in the first model

stat

one or more functions of the parameters using "x" and "y" as placeholders for the parameters from the first and second model, respectively. Default: Compute (A) the difference between parameters and (B) a Bayesian p-value (by counting how often x<y).

plot

whether to plot the convergence of the difference in parameters

Value

a list of the class betweenMPT with the values:

summary: Summary for parameter difference
mptInfo1, mptInfo2: info about MPT models (eqn and data file etc.)
mcmc: the MCMC samples of the differences in parameters

Author(s)

Daniel Heck

Posterior Distribution for Correlations

Description

Adjusts the posterior distribution of correlations for the sampling error of a population correlation according to the sample size (i.e., the number of participants; Ly, Marsman, & Wagenmakers, 2018).

Usage

correlationPosterior(
  fittedModel,
  r,
  N,
  kappa = 1,
  ci = 0.95,
  M = 1000,
  precision = 0.005,
  maxiter = 10000,
  plot = TRUE,
  nCPU = 4
)

Arguments

fittedModel

a fitted betaMPT or traitMPT model with covariates (added during fitting by the argument covData)

r

optional: a vector of posterior correlations (instead of fittedModel)

N

only if r is used: the number of participants the correlation is based on

kappa

parameter for the prior of the correlation, that is, a scaled beta distribution: Beta(1/kappa, 1/kappa). The default kappa=1 defines a uniform distribution on [-1,1], whereas kappa<1 defines a unimodal prior centered around zero.

ci

credibility interval

M

number of subsamples from the fitted model

precision

precision on the interval [-1,1] to approximate the posterior density

maxiter

maximum number of iterations in genhypergeo. Higher values might be necessary to increase numerical stability for large correlations (r>.95).

plot

whether to plot (a) the unadjusted posterior correlations (gray histogram) and (b) the corrected posterior (black line with red credibility intervals)

nCPU

number of CPUs used for parallel computation of posterior distribution

Details

This function (1) uses all posterior samples of a correlation to (2) derive the posterior of the correlation corrected for sampling error and (3) averages these densities across the posterior samples. Thereby, the method accounts for estimation uncertainty of the MPT model (due to the use of the posterior samples) and also for sampling error of the population correlation due to sample size (cf. Ly, Boehm, Heathcote, Turner, Forstmann, Marsman, & Matzke, 2016).

Author(s)

Daniel W. Heck, Alexander Ly

References

Ly, A., Marsman, M., & Wagenmakers, E.-J. (2018). Analytic posteriors for Pearson’s correlation coefficient. Statistica Neerlandica, 72, 4–13. doi:10.1111/stan.12111

Ly, A., Boehm, U., Heathcote, A., Turner, B. M. , Forstmann, B., Marsman, M., and Matzke, D. (2017). A flexible and efficient hierarchical Bayesian approach to the exploration of individual differences in cognitive-model-based neuroscience. https://osf.io/evsyv/. doi:10.1002/9781119159193

Examples

# test effect of number of participants:
set.seed(123)
cors <- rbeta(50, 100, 70)
correlationPosterior(r = cors, N = 10, nCPU = 1)
correlationPosterior(r = cors, N = 100, nCPU = 1)

Extend MCMC Sampling for MPT Model

Description

Adds more MCMC samples to the fitted MPT model.

Usage

extendMPT(fittedModel, n.iter = 10000, n.adapt = 1000, n.burnin = 0, ...)

Arguments

fittedModel

a fitted traitMPT or betaMPT

n.iter

Number of iterations per chain (including burnin samples). See run.jags for details.

n.adapt

n.burnin

Number of samples for burnin (samples will not be stored and removed from n.iter)

...

further arguments passed to extend.jags (see arguments listed in: run.jags).

When drawing more samples, JAGS requires an additional adaptation phase, in which the MCMC sampling procedure is adjusted. Note that the MCMC sampling will still give correct results even if the warning appears: "Adaptation incomplete." (this just means that sampling efficiency is not optimal).

Generate Data for Beta MPT Models

Description

Generating a data file with known parameter structure using the Beta-MPT. Useful for simulations and robustness checks.

Usage

genBetaMPT(
  N,
  numItems,
  eqnfile,
  restrictions,
  mean = NULL,
  sd = NULL,
  alpha = NULL,
  beta = NULL,
  warning = TRUE
)

Arguments

N

number of participants

numItems

number of responses per tree (a named vector with tree labels)

eqnfile

restrictions

mean

Named vector of true group means of individual MPT parameters. If the vector is not named, the internal order of parameters is used (can be obtained using readEQN).

sd

named vector of group standard deviations of individual MPT parameters.

alpha

Alternative specification of the group-level distribution using the shape parameters of the beta distribution (see dbeta).

beta

see alpha

warning

whether to show warning in case the naming of data-generating parameters are unnamed or do not match

Details

Data are generated in a two-step procedure. First, person parameters are sampled from the specified beta distributions for each paramter (either based on mean/sd or based on alpha/beta). In a second step, response frequencies are sampled for each person using genMPT.

Value

a list including the generated frequencies (data) and the true, underlying parameters (parameters) on the group and individual level.

References

Smith, J. B., & Batchelder, W. H. (2010). Beta-MPT: Multinomial processing tree models for addressing individual differences. Journal of Mathematical Psychology, 54, 167-183.

Examples

# Example: Standard Two-High-Threshold Model (2HTM)
EQNfile <- system.file("MPTmodels/2htm.eqn", package = "TreeBUGS")
genDat <- genBetaMPT(
  N = 100,
  numItems = c(Target = 250, Lure = 250),
  eqnfile = EQNfile,
  mean = c(Do = .7, Dn = .5, g = .5),
  sd = c(Do = .1, Dn = .1, g = .05)
)
head(genDat$data, 3)
plotFreq(genDat$data, eqn = EQNfile)

Generate MPT Frequencies

Description

Uses a matrix of individual MPT parameters to generate MPT frequencies.

Usage

genMPT(theta, numItems, eqnfile, restrictions, warning = TRUE)

Arguments

theta

matrix of MPT parameters (rows: individuals; columns: parameters). Parameters are assigned by column names of the matrix. all of the parameters in the model file need to be included.

numItems

number of responses per tree (a named vector with tree labels)

eqnfile

restrictions

warning

whether to show warning in case the naming of data-generating parameters are unnamed or do not match

Examples

# Example: Standard Two-High-Threshold Model (2HTM)
EQNfile <- system.file("MPTmodels/2htm.eqn", package = "TreeBUGS")
theta <- matrix(
  c(
    .8, .4, .5,
    .6, .3, .4
  ),
  nrow = 2, byrow = TRUE,
  dimnames = list(NULL, c("Do", "Dn", "g"))
)
genDat <- genMPT(
  theta, c(Target = 250, Lure = 250),
  EQNfile
)
genDat

Generate Data for Latent-Trait MPT Models

Description

Generating a data set with known parameter structure using the Trait-MPT. Useful for simulations and robustness checks.

Usage

genTraitMPT(
  N,
  numItems,
  eqnfile,
  restrictions,
  mean,
  mu,
  sigma,
  rho,
  warning = TRUE
)

Arguments

N

number of participants

numItems

number of responses per tree (a named vector with tree labels)

eqnfile

restrictions

mean

named vector of data-generating group means of the individual MPT parameters on the probability scale. If the vector is not named, the internal order of parameters is used (can be obtained using readEQN).

mu

an alternative way to define the group-level means on the latent-probit scale (i.e., mu = qnorm(mean) or equivalently, mean = pnorm(mu)).

sigma

(named) vector of group standard deviations of individual MPT parameters on the latent probit scale. Default is zero (no person heterogeneity).

rho

(named) correlation matrix for individual MPT parameters on the latent probit scale. Must be symmetric and positive definite (e.g., no correlations of 1 or -1 allowed). Default: a diagonal matrix (i.e., zero correlations).

warning

whether to show warning in case the naming of data-generating parameters are unnamed or do not match

Details

This functions implements a two-step sampling procedure. First, the person parameters on the latent probit-scale are sampled from the multivariate normal distribution (based on the mean mu = qnorm(mean), the standard deviations sigma, and the correlation matrix rho). These person parameters are then transformed to the probability scale using the probit-link. In a last step, observed frequencies are sampled for each person using the MPT equations.

Note that the user can generate more complex structures for the latent person parameters, and then supply these person parameters to the function genMPT.

Value

a list including the generated frequencies per person (data) and the sampled individual parameters (parameters) on the probit and probability scale (thetaLatent and theta, respectively).

References

Klauer, K. C. (2010). Hierarchical multinomial processing tree models: A latent-trait approach. Psychometrika, 75, 70-98.

Examples

# Example: Standard Two-High-Threshold Model (2HTM)
EQNfile <- system.file("MPTmodels/2htm.eqn", package = "TreeBUGS")
rho <- matrix(c(
  1, .8, .2,
  .8, 1, .1,
  .2, .1, 1
), nrow = 3)
colnames(rho) <- rownames(rho) <- c("Do", "Dn", "g")
genDat <- genTraitMPT(
  N = 100,
  numItems = c(Target = 250, Lure = 250),
  eqnfile = EQNfile,
  mean = c(Do = .7, Dn = .7, g = .5),
  sigma = c(Do = .3, Dn = .3, g = .15),
  rho = rho
)
head(genDat$data, 3)
plotFreq(genDat$data, eqn = EQNfile)

Get Mean Parameters per Group

Description

For hierarchical latent-trait MPT models with discrete predictor variables as fitted with traitMPT(..., predStructure = list("f")).

Usage

getGroupMeans(
  traitMPT,
  factor = "all",
  probit = FALSE,
  file = NULL,
  mcmc = FALSE
)

Arguments

traitMPT

a fitted traitMPT model

factor

whether to get group estimates for all combinations of factor levels (default) or only for specific factors (requires the names of the covariates in covData)

probit

whether to use probit scale or probability scale

file

filename to export results in .csv format (e.g., file="fit_group.csv")

mcmc

if TRUE, the raw MCMC samples for the group means are returned as an mcmc.list object. This allows pairwise tests of group means (see transformedParameters).

Author(s)

Daniel Heck

Examples

## Not run:
# save group means (probability scale):
getGroupMeans(traitMPT, file = "groups.csv")

## End(Not run)

Get Parameter Posterior Statistics

Description

Returns posterior statistics (e.g., mean, median) for the parameters of a hierarchical MPT model.

Usage

getParam(fittedModel, parameter = "mean", stat = "mean", file = NULL)

Arguments

fittedModel

a fitted latent-trait MPT model (see traitMPT) or beta MPT model (see betaMPT)

parameter

which parameter(s) of the (hierarchical) MPT model should be returned? (see details in getParam).

stat

whether to get the posterior "mean", "median", "sd", or "summary" (includes mean, SD, and 95% credibility interval)

file

filename to export results in .csv format (e.g., file="est_param.csv")

Details

This function is a convenient way to get the information stored in fittedModel$mcmc.summ.

The latent-trait MPT includes the following parameters:

"mean" (group means on probability scale)
"mu" (group means on probit scale)
"sigma" (SD on probit scale)
"rho" (correlations on probit scale)
"theta" (individual MPT parameters)

The beta MPT includes the following parameters:

"mean" (group means on probability scale)
"sd" (SD on probability scale)
"alph","bet" (group parameters of beta distribution)
"theta" (individual MPT parameters)

Author(s)

Daniel Heck

Examples

## Not run:
# mean estimates per person:
getParam(fittedModel, parameter = "theta")

# save summary of individual estimates:
getParam(fittedModel,
  parameter = "theta",
  stat = "summary", file = "ind_summ.csv"
)

## End(Not run)

Get Posterior Samples from Fitted MPT Model

Description

Extracts MCMC posterior samples as an coda::mcmc.list and relabels the MCMC variables.

Usage

getSamples(
  fittedModel,
  parameter = "mean",
  select = "all",
  names = "par_label"
)

Arguments

fittedModel

a fitted latent-trait MPT model (see traitMPT) or beta MPT model (see betaMPT)

parameter

which parameter(s) of the (hierarchical) MPT model should be returned? (see details in getParam).

select

character vector of parameters to be plotted (e.g., select = c("d", "g"). Can be used to plot subsets of parameters and change the order of parameters.

names

whether and how to rename the variables in the MCMC output: par (internal parameter labels such as mu[1]), label (MPT label from EQN file such as "d"), or par_name (concatenation of both such as "mu[1]_d").

Examples

## Not run:
getSamples(fittedModel, "mu", select = c("d", "g"))

## End(Not run)

Marginal Likelihood for Simple MPT

Description

Computes the marginal likelihood for simple (fixed-effects, nonhierarchical) MPT models.

Usage

marginalMPT(
  eqnfile,
  data,
  restrictions,
  alpha = 1,
  beta = 1,
  dataset = 1,
  method = "importance",
  posterior = 500,
  mix = 0.05,
  scale = 0.9,
  samples = 10000,
  batches = 10,
  show = TRUE,
  cores = 1
)

Arguments

eqnfile

data

restrictions

alpha

first shape parameter(s) for the beta prior-distribution of the MPT parameters \theta_s (can be a named vector to use a different prior for each MPT parameter)

beta

second shape parameter(s)

dataset

for which data set should Bayes factors be computed?

method

either "importance" (importance sampling using a mixture of uniform and beta-aproximation of the posterior) or "prior" (brute force Monte Carlo sampling from prior)

posterior

number of posterior samples used to approximate importance-sampling densities (i.e., beta distributions)

mix

mixture proportion of the uniform distribution for the importance-sampling density

scale

how much should posterior-beta approximations be downscaled to get fatter importance-sampling density

samples

total number of samples from parameter space

batches

number of batches. Used to compute a standard error of the estimate.

show

whether to show progress

cores

number of CPUs used

Details

Currently, this is only implemented for a single data set!

If method = "prior", a brute-force Monte Carlo method is used and parameters are directly sampled from the prior.Then, the likelihood is evaluated for these samples and averaged (fast, but inefficient).

Alternatively, an importance sampler is used if method = "importance", and the posterior distributions of the MPT parameters are approximated by independent beta distributions. Then each parameter s is sampled from the importance density:

mix*U(0,1) + (1-mix)*Beta(scale*a_s, scale*b_s)

References

Vandekerckhove, J. S., Matzke, D., & Wagenmakers, E. (2015). Model comparison and the principle of parsimony. In Oxford Handbook of Computational and Mathematical Psychology (pp. 300-319). New York, NY: Oxford University Press.

Examples

# 2-High-Threshold Model
eqn <- "## 2HTM ##
   Target  Hit  d
   Target  Hit  (1-d)*g
   Target  Miss (1-d)*(1-g)
   Lure    FA   (1-d)*g
   Lure    CR   (1-d)*(1-g)
   Lure    CR   d"
data <- c(
  Hit = 46, Miss = 14,
  FA = 14, CR = 46
)

# weakly informative prior for guessing
aa <- c(d = 1, g = 2)
bb <- c(d = 1, g = 2)
curve(dbeta(x, aa["g"], bb["g"]))

# compute marginal likelihood
htm <- marginalMPT(eqn, data,
  alpha = aa, beta = bb,
  posterior = 200, samples = 1000
)
# second model: g=.50
htm.g50 <- marginalMPT(eqn, data, list("g=.5"),
  alpha = aa, beta = bb,
  posterior = 200, samples = 1000
)

# Bayes factor
# (per batch to get estimation error)
bf <- htm.g50$p.per.batch / htm$p.per.batch
mean(bf) # BF
sd(bf) / sqrt(length(bf)) # standard error of BF estimate

Plot Convergence for Hierarchical MPT Models

Description

Plot Convergence for Hierarchical MPT Models

Usage

## S3 method for class 'betaMPT'
plot(x, parameter = "mean", type = "default", ...)

## S3 method for class 'simpleMPT'
plot(x, type = "default", ...)

## S3 method for class 'traitMPT'
plot(x, parameter = "mean", type = "default", ...)

Arguments

x

fitted hierarchical MPT model (traitMPT, betaMPT)

parameter

which parameter to plot (e.g., "theta", "mean", "rho", "slope"). Parameters are matched partially, in order to plot all entries of vector valued parameters (see getParam to get a list of parameters). Moreover, parameter labels can be used, e.g., "theta[D]" or "rho[D,g]"

type

type of convergence plot. Can be one of "default" (trace+density), "acf" (auto-correlation function), "trace", "autocorr", "crosscorr","density", "gelman". See plotting functions in the coda package (plot.mcmc.list, acfplot, traceplot, autocorr.plot, crosscorr.plot, densplot, gelman.plot ).

...

further arguments passed to the plotting functions in coda

Methods (by class)

plot(betaMPT): Plot convergence for beta MPT
plot(simpleMPT): Plot convergence for nonhierarchical MPT model
plot(traitMPT): Plot convergence for latent-trait MPT

Plot Distribution of Individual Estimates

Description

Plots histograms of the posterior-means of individual MPT parameters against the group-level distribution given by the posterior-mean of the hierarchical parameters (e.g., the beta distribution in case of the beta-MPT)

Usage

plotDistribution(fittedModel, scale = "probability", ...)

Arguments

fittedModel

fitted latent-trait or beta MPT model (traitMPT, betaMPT)

scale

only for latent-trait MPT: should estimates be plotted on the "latent" or the "probability" scale (i.e., as MPT parameters). Can be abbreviated by "l" and "p".

...

further arguments passed to hist (e.g., breaks=50 to get a more fine-grained histogram)

Details

For the latent-trait MPT, differences due to continuous predictors or discrete factors are currently not considered in the group-level predictions (red density). Under such a model, individual estimates are not predicted to be normally distributed on the latent scale as shown in the plot.

Plot Posterior Predictive Mean Frequencies

Description

Plots observed means/covariances of individual frequencies against the means/covariances sampled from the posterior distribution (posterior predictive distribution).

Usage

plotFit(fittedModel, M = 1000, stat = "mean", ...)

Arguments

fittedModel

fitted latent-trait or beta MPT model (traitMPT, betaMPT)

M

number of posterior predictive samples. As a maximum, the number of posterior samples in fittedModel is used.

stat

whether to plot mean frequencies ("mean") or covariances of individual frequencies ("cov")

...

arguments passed to boxplot

Details

If posterior predictive p-values were computed when fitting the model (e.g., by adding the argument traitMPT(...,ppp=1000) ), the stored posterior samples are re-used for plotting. Note that the last category in each MPT tree is dropped, because one category per multinomial distribution is fixed.

Examples

## Not run:
# add posterior predictive samples to fitted model (optional step)
fittedModel$postpred$freq.pred <-
  posteriorPredictive(fittedModel, M = 1000)

# plot model fit
plotFit(fittedModel, stat = "mean")

## End(Not run)

Plot Raw Frequencies

Description

Plot observed individual and mean frequencies.

Usage

plotFreq(x, freq = TRUE, select = "all", boxplot = TRUE, eqnfile, ...)

Arguments

x

either a fitted hierarchical MPT model (see traitMPT, betaMPT); or a matrix/data frame of response frequencies (can be provided as a path to a .csv-file with individual frequencies).

freq

whether to plot absolute frequencies or relative frequencies (which sum up to one within each tree; only if x is a hierarchical model or if eqnfile is provided)

select

a numeric vector with participant indices to select which raw frequencies to plot (default: "all")

boxplot

if FALSE, lines and points are drawn instead of boxplots

eqnfile

optional: EQN description of an MPT model, that is, either the path to an EQN file or as a character string (only used if x refers to a matrix/data frame or .csv-file)

...

further arguments passed to boxplot and plot

Examples

# get frequency data and EQN file
freq <- subset(arnold2013, group == "encoding", select = -(1:4))
eqn <- system.file("MPTmodels/2htsm.eqn", package = "TreeBUGS")
plotFreq(freq, eqnfile = eqn)
plotFreq(freq, freq = FALSE, eqnfile = eqn)

Plot Parameter Estimates

Description

Plot parameter estimates for hierarchical MPT models.

Usage

plotParam(
  x,
  includeIndividual = TRUE,
  addLines = FALSE,
  estimate = "mean",
  select = "all",
  ...
)

Arguments

x

a fitted Beta or latent-trait MPT model

includeIndividual

whether to plot individual estimates

addLines

whether to connect individual parameter estimates by lines

estimate

type of point estimates for group-level and individual parameters (either "mean" or "median")

select

character vector of parameters to be plotted (e.g., select = c("d", "g"). Can be used to plot subsets of parameters and change the order of parameters.

...

further arguments passed to the standard plot function

Author(s)

Daniel Heck

Examples

## Not run:
plotParam(fit,
  addLines = TRUE,
  estimate = "median",
  select = c("d1", "d2")
)

## End(Not run)

Plot Prior Distributions

Description

Plots prior distributions for group means, standard deviation, and correlations of MPT parameters across participants.

Usage

plotPrior(prior, probitInverse = "mean", M = 5000, nCPU = 3, ...)

Arguments

prior

a named list defining the priors. For the traitMPT, the default is list(mu = "dnorm(0,1)", xi="dunif(0,10)", V=diag(S), df=S+1), where S is the number of free parameters. For the betaMPT, the default is list(alpha ="dgamma(1,.1)", beta = "dgamma(1,.1)"). Note that the normal distribution "dnorm(mu,prec)" is parameterized as in JAGS by the mean and precision (= 1/variance).

probitInverse

which latent-probit parameters (for traitMPT model) to transform to probability scale. Either "none", "mean" (simple transformation \Phi(\mu)), or "mean_sd" (see probitInverse)

M

number of random samples to approximate priors of group-level parameters

nCPU

number of CPUs used for parallel sampling. For large models and many participants, this may require a lot of memory.

...

further arguments passed to plot

Details

This function samples from a set of hyperpriors (either for hierarchical traitMPT or betaMPT structure) to approximate the implied prior distributions on the parameters of interest (group-level mean, SD, and correlations of MPT parameters). Note that the normal distribution "dnorm(mu,prec)" is parameterized as in JAGS by the mean and precision (= 1/variance).

Examples

## Not run:
# default priors for traitMPT:
plotPrior(list(
  mu = "dnorm(0, 1)",
  xi = "dunif(0, 10)",
  V = diag(2),
  df = 2 + 1
), M = 4000)

# default priors for betaMPT:
plotPrior(list(
  alpha = "dgamma(1, 0.1)",
  beta = "dgamma(1, 0.1)"
), M = 4000)

## End(Not run)

Plot Prior vs. Posterior Distribution

Description

Allows to judge how much the data informed the parameter posterior distributions compared to the prior.

Usage

plotPriorPost(
  fittedModel,
  probitInverse = "mean",
  M = 2e+05,
  ci = 0.95,
  nCPU = 3,
  ...
)

Arguments

fittedModel

fitted latent-trait or beta MPT model (traitMPT, betaMPT)

probitInverse

which latent-probit parameters (for traitMPT model) to transform to probability scale. Either "none", "mean" (simple transformation \Phi(\mu)), or "mean_sd" (see probitInverse)

M

number of random samples to approximate prior distributions

ci

credibility interval indicated by vertical red lines

nCPU

number of CPUs used for parallel sampling. For large models and many participants, this may require a lot of memory.

...

arguments passed to boxplot

Details

Prior distributions are shown as blue, dashed lines, whereas posterior distributions are shown as solid, black lines.

Get Posterior Predictive Samples

Description

Draw predicted frequencies based on posterior distribution of (a) individual estimates (default) or (b) for a new participant (if numItems is provided; does not consider continuous or discrete predictors in traitMPT).

Usage

posteriorPredictive(
  fittedModel,
  M = 100,
  numItems = NULL,
  expected = FALSE,
  nCPU = 4
)

Arguments

fittedModel

fitted latent-trait or beta MPT model (traitMPT, betaMPT)

M

number of posterior predictive samples. As a maximum, the number of posterior samples in fittedModel is used.

numItems

optional: a vector with the number of items per MPT tree to sample predicted data for a new participant (first, a participant vector \theta is sampled from the hierarchical posterior; second, frequencies are generated).

expected

if TRUE, the expected frequencies per person are returned (without additional sampling from a multinomial distribution)

nCPU

number of CPUs used for parallel sampling. For large models and many participants, this requires considerable computer-memory resources (as a remedy, use nCPU=1).

Value

by default, a list of M posterior-predictive samples (i.e., matrices) with individual frequencies (rows=participants, columns=MPT categories). For M=1, a single matrix is returned. If numItems is provided, a matrix with samples for a new participant is returned (rows=samples)

Examples

## Not run:
# add posterior predictive samples to fitted model
#     (facilitates plotting using ?plotFit)
fittedModel$postpred$freq.pred <-
  posteriorPredictive(fittedModel, M = 1000)

## End(Not run)

Prior Predictive Samples

Description

Samples full data sets (i.e., individual response frequencies) or group-level MPT parameters based on prior distribution for group-level parameters.

Usage

priorPredictive(
  prior,
  eqnfile,
  restrictions,
  numItems,
  level = "data",
  N = 1,
  M = 100,
  nCPU = 4
)

Arguments

prior

eqnfile

restrictions

numItems

vector with the number of items per MPT tree (either named or assigned to alphabetically ordered tree labels)

level

either "data" (returns individual frequencies) or "parameter" (returns group-level MPT parameters; M and numItems are ignored)

N

number of participants per replication

M

number of prior predictive samples (i.e., data sets with N participants).

nCPU

number of CPUs used for parallel sampling. For large models and many participants, this may require a lot of memory.

Value

a list of M matrices with individual frequencies (rows=participants, columns=MPT categories). A single matrix is returned if M=1 or level="parameter".

Examples

eqnfile <- system.file("MPTmodels/2htm.eqn",
  package = "TreeBUGS"
)
### beta-MPT:
prior <- list(
  alpha = "dgamma(1,.1)",
  beta = "dgamma(1,.1)"
)

### prior-predictive frequencies:
priorPredictive(prior, eqnfile,
  restrictions = list("g=.5", "Do=Dn"),
  numItems = c(50, 50), N = 10, M = 1, nCPU = 1
)

### prior samples of group-level parameters:
priorPredictive(prior, eqnfile,
  level = "parameter",
  restrictions = list("g=.5", "Do=Dn"),
  M = 5, nCPU = 1
)

### latent-trait MPT
priorPredictive(
  prior = list(
    mu = "dnorm(0,1)", xi = "dunif(0,10)",
    df = 3, V = diag(2)
  ),
  eqnfile, restrictions = list("g=.5"),
  numItems = c(50, 50), N = 10, M = 1, nCPU = 1
)

Probit-Inverse of Group-Level Normal Distribution

Description

Transform latent group-level normal distribution (latent-trait MPT) into mean and SD on probability scale.

Usage

probitInverse(mu, sigma, fittedModel = NULL)

Arguments

mu

latent-probit mean of normal distribution

sigma

latent-probit SD of normal distribution

fittedModel

optional: fitted traitMPT model. If provided, the bivariate inverse-probit transform is applied to all MCMC samples (and mu and sigma are ignored).

Value

implied mean and SD on probability scale

Examples

####### compare bivariate vs. univariate transformation
probitInverse(mu = 0.8, sigma = c(0.25, 0.5, 0.75, 1))
pnorm(0.8)

# full distribution
prob <- pnorm(rnorm(10000, mean = 0.8, sd = 0.7))
hist(prob, 80, col = "gray", xlim = 0:1)

## Not run:
# transformation for fitted model
mean_sd <- probitInverse(fittedModel = fit)
summarizeMCMC(mean_sd)

## End(Not run)

Read multiTree files

Description

Function to import MPT models from standard .eqn model files as used, for instance, by multiTree (Moshagen, 2010).

Usage

readEQN(file, restrictions = NULL, paramOrder = FALSE, parse = FALSE)

Arguments

file

The (full path to the) file that specifies the MPT model (standard .eqn syntax). Note that category labels must start with a letter (different to multiTree) and match the column names of data. Alternatively, the EQN-equations can be provided within R as a character value (see examples). Note that the first line of an .eqn-file is reserved for comments and always ignored.

restrictions

paramOrder

if TRUE, the order of MPT parameters as interally used is printed.

parse

whether to return a parsed MPT model description in terms of the matrices a and b (the powers of the \theta and (1-\theta), respectively, and the vector of constants c. Each branch probability is then given as c_{i} \prod_{s} \theta^{a_{i,s}}(1-\theta)^{b_{i,s}})

Details

The file format should adhere to the standard .eqn-syntax (note that the first line is skipped and can be used for comments). In each line, a separate branch of the MPT model is specified using the tree label, category label, and the model equations in full form (multiplication sign '*' required; not abbreviations such as 'a^2' allowed).

As an example, the standard two-high threshold model (2HTM) is defined as follows:

`Target`	`Hit`	`Do`
`Target`	`Hit`	`(1-Do)*g`
`Target`	`Miss`	`(1-Do)*(1-g)`
`Lure`	`FalseAlarm`	`(1-Dn)*g`
`Lure`	`CorrectReject`	`(1-Dn)*(1-g)`
`Lure`	`CorrectReject`	`Dn`

Author(s)

Daniel Heck, Denis Arnold, Nina Arnold

References

Moshagen, M. (2010). multiTree: A computer program for the analysis of multinomial processing tree models. Behavior Research Methods, 42, 42-54.

Examples

# Example: Standard Two-High-Threshold Model (2HTM)
EQNfile <- system.file("MPTmodels/2htm.eqn",
  package = "TreeBUGS"
)
readEQN(file = EQNfile, paramOrder = TRUE)

# with equality constraint:
readEQN(
  file = EQNfile, restrictions = list("Dn = Do", "g = 0.5"),
  paramOrder = TRUE
)

# define MPT model directly within R
model <-
  "2-High Threshold Model (2HTM)
  old hit d
  old hit (1-d)*g
  old miss (1-d)*(1-g)
  new fa (1-d)*g
  new cr (1-d)*(1-g)
  new cr d"
readEQN(model, paramOrder = TRUE)

C++ Sampler for Standard (Nonhierarchical) MPT Models

Description

Fast Gibbs sampler in C++ that is tailored to the standard fixed-effects MPT model (i.e., fixed-effects, non-hierarchical MPT). Assumes independent parameters per person if a matrix of frequencies per person is supplied.

Usage

simpleMPT(
  eqnfile,
  data,
  restrictions,
  n.iter = 2000,
  n.burnin = 500,
  n.thin = 3,
  n.chains = 3,
  ppp = 0,
  alpha = 1,
  beta = 1,
  parEstFile,
  posteriorFile,
  cores = 1
)

Arguments

eqnfile

data

restrictions

n.iter

Number of iterations per chain (including burnin samples). See run.jags for details.

n.burnin

Number of samples for burnin (samples will not be stored and removed from n.iter)

n.thin

Thinning rate.

n.chains

number of MCMC chains (sampled in parallel).

ppp

number of samples to compute posterior predictive p-value (see posteriorPredictive)

alpha

first shape parameter(s) for the beta prior-distribution of the MPT parameters \theta_s (can be a named vector to use a different prior for each MPT parameter)

beta

second shape parameter(s)

parEstFile

Name of the file to with the estimates should be stored (e.g., "parEstFile.txt")

posteriorFile

path to RData-file where to save the model including MCMC posterior samples (an object named fittedModel; e.g., posteriorFile="mcmc.RData")

cores

number of CPUs to be used

Details

Beta distributions with fixed shape parameters \alpha and \beta are used. The default \alpha=1 and \beta=1 assumes uniform priors for all MPT parameters.

Author(s)

Daniel Heck

Examples

## Not run:
# fit nonhierarchical MPT model for aggregated data (see ?arnold2013):
EQNfile <- system.file("MPTmodels/2htsm.eqn", package = "TreeBUGS")
d.encoding <- subset(arnold2013, group == "encoding", select = -(1:4))
fit <- simpleMPT(EQNfile, colSums(d.encoding),
  restrictions = list("D1=D2=D3", "d1=d2", "a=g")
)
# convergence
plot(fit)
summary(fit)

## End(Not run)

MCMC Summary

Description

TreeBUGS-specific MCMC summary for mcmc.list-objects.

Usage

summarizeMCMC(mcmc, batchSize = 50, probs = c(0.025, 0.5, 0.975))

Arguments

mcmc

a mcmc.list object

batchSize

size of batches of parameters used to reduce memory load when computing posterior summary statistics (including Rhat and effective sample size).

probs

quantile probabilities used to compute credibility intervals

Summarize JAGS Output for Hierarchical MPT Models

Description

Provide clean and readable summary statistics tailored to MPT models based on the JAGS output.

Usage

summarizeMPT(mcmc, mptInfo, probs = c(0.025, 0.5, 0.975), summ = NULL)

Arguments

mcmc

the actual mcmc.list output of the sampler of a fitted MPT model (accesible via fittedModel$runjags$mcmc)

mptInfo

the internally stored information about the fitted MPT model (accesible via fittedModel$mptInfo)

probs

quantile probabilities used to compute credibility intervals

summ

optional argument for internal use

Details

The MPT-specific summary is computed directly after fitting a model. However, this function might be used manually after removing MCMC samples (e.g., extending the burnin period).

Examples

# Remove additional burnin samples and recompute MPT summary
## Not run:
# start later or thin (see ?window)
mcmc.subsamp <- window(fittedModel$runjags$mcmc, start = 3001, thin = 2)
new.mpt.summary <- summarizeMPT(mcmc.subsamp, fittedModel$mptInfo)
new.mpt.summary

## End(Not run)

Chi-Square Test of Heterogeneity

Description

Tests whether whether participants (items) are homogeneous under the assumption of item (participant) homogeneity.

Usage

testHetChi(freq, tree)

Arguments

freq

matrix with observed frequencies (rows: persons/items; columns: categories). Can also be the path to a .csv file with frequencies (comma-separated; first line defines category labels)

tree

a vector defining which columns of x belong to separate multinomial distributions (i.e., MPT trees). For instance, if x has five categories from two MPT trees: tree=c(1,1,2,2,2) or tree=c("t1","t1","t2","t2","t2")

Details

If an item/person has zero frequencies on all categories in an MPT tree, these zeros are neglected when computing mean frequencies per column. As an example, consider a simple recognition test with a fixed assignments of words to the learn/test list. In such an experiment, all learned words will result in hits or misses (i.e., the MPT tree of old items), whereas new words are always false alarms/correct rejections and thus belong to the MPT tree of new items (this is not necessarily the case if words are assigned randomly).

Note that the test assumes independence of observations and item homogeneity when testing participant heterogeneity. The latter assumption can be dropped when using a permutation test (testHetPerm).

Author(s)

Daniel W. Heck

References

Smith, J. B., & Batchelder, W. H. (2008). Assessing individual differences in categorical data. Psychonomic Bulletin & Review, 15, 713-731. doi:10.3758/PBR.15.4.713

Examples

# some made up frequencies:
freq <- matrix(
  c(
    13, 16, 11, 13,
    15, 21, 18, 13,
    21, 14, 16, 17,
    19, 20, 21, 18
  ),
  ncol = 4, byrow = TRUE
)
# for a product-binomial distribution:
# (categories 1 and 2 and categories 3 and 4 are binomials)
testHetChi(freq, tree = c(1, 1, 2, 2))
# => no significant deviation from homogeneity (low power!)

Permutation Test of Heterogeneity

Description

Tests whether whether participants (items) are homogeneous without assuming item (participant) homogeneity.

Usage

testHetPerm(data, tree, source = "person", rep = 1000, nCPU = 4)

Arguments

data

matrix or data frame with three columns: person code/index, item label, response category. Can also be the path to a .csv file with frequencies (comma-separated; first line defines category labels)

tree

a list that defines which categories belong to the same multinomial distribution (i.e., the the same MPT tree). For instance: tree = list(tree.old = c("hit","cr"), tree.new = c("fa","miss")). Category labels must match the values of the third column of data

source

whether to test for "person" or "item" homogeneity

rep

number of permutations to be sampled

nCPU

number of CPUs used for parallel Monte Carlo sampling of permutations

Details

Note that the test does still assume independence of observations. However, it does not require item homogeneity when testing participant heterogeneity (in contrast to the chi-square test: testHetChi).

Author(s)

Daniel W. Heck

References

Smith, J. B., & Batchelder, W. H. (2008). Assessing individual differences in categorical data. Psychonomic Bulletin & Review, 15, 713-731. doi:10.3758/PBR.15.4.713

Examples

# generate homogeneous data
# (N=15 participants, M=30 items)
data <- data.frame(
  id = rep(1:15, each = 30),
  item = rep(1:30, 15)
)
data$cat <- sample(c("h", "cr", "m", "fa"), 15 * 30,
  replace = TRUE,
  prob = c(.7, .3, .4, .6)
)
head(data)
tree <- list(
  old = c("h", "m"),
  new = c("fa", "cr")
)

# test participant homogeneity:
tmp <- testHetPerm(data, tree, rep = 200, nCPU = 1)
tmp[2:3]

Fit a Hierarchical Latent-Trait MPT Model

Description

Fits a latent-trait MPT model (Klauer, 2010) based on a standard MPT model file (.eqn) and individual data table (.csv).

Usage

traitMPT(
  eqnfile,
  data,
  restrictions,
  covData,
  predStructure,
  predType,
  transformedParameters,
  corProbit = TRUE,
  mu = "dnorm(0,1)",
  xi = "dunif(0,10)",
  V,
  df,
  IVprec = "dgamma(.5,.5)",
  n.iter = 20000,
  n.adapt = 2000,
  n.burnin = 2000,
  n.thin = 5,
  n.chains = 3,
  dic = FALSE,
  ppp = 0,
  monitorIndividual = TRUE,
  modelfilename,
  parEstFile,
  posteriorFile,
  autojags = NULL,
  ...
)

Arguments

eqnfile

data

restrictions

covData

predStructure

Defines which variables in covData are included as predictors for which MPT parameters. Either the path to the file that specifies the assignment of MPT parameters to covariates (that is, each row assigns one or more MPT parameters to one or more covariates, separated by a semicolon, e.g., Do g; age extraversion). Can also be provided as a list, e.g., list("Do Dn ; age", "g ; extraversion"). Note that no correlations of MPT parameters and predictors are computed. However, for continuous covariates, the standardized slope parameters slope_std_parameter_predictor can be interpreted as a correlation if a single predictor is included for the corresponding MPT parameter (see Jobst et al., 2020).

predType

a character vector specifying the type of continuous or discrete predictors in each column of covData: "c" = continuous covariate (which are centered to have a mean of zero); "f" = discrete predictor, fixed effect (default for character/factor variables); "r" = discrete predictor, random effect.

transformedParameters

corProbit

mu

hyperprior for group means of probit-transformed parameters in JAGS syntax. Default is a standard normal distribution, which implies a uniform distribution on the MPT probability parameters. A named vector can be used to specify separate hyperpriors for each MPT parameter (the order of parameters is determined by the names of the vector or by the default order as shown in readEQN with paramOrder = TRUE).

xi

hyperprior for scaling parameters of the group-level parameter variances. Default is a uniform distribution on the interval [0,10]. Similarly as for mu, a vector of different priors can be used. Less informative priors can be used (e.g., "dunif(0,100)")) but might result in reduced stability.

V

S x S matrix used as a hyperprior for the inverse-Wishart hyperprior parameters with as many rows and columns as there are core MPT parameters. Default is a diagonal matrix.

df

degrees of freedom for the inverse-Wishart hyperprior for the individual parameters. Minimum is S+1, where S gives the number of core MPT parameters.

IVprec

hyperprior on the precision parameter g (= the inverse of the variance) of the standardized slope parameters of continuous covariates. The default IVprec=dgamma(.5,.5) defines a mixture of g-priors (also known as JZS or Cauchy prior) with the scale parameter s=1. Different scale parameters s can be set via: IVprec=dgamma(.5,.5*s^2). A numeric constant IVprec=1 implies a g-prior (a normal distribution). For ease of interpretation, TreeBUGS reports both unstandardized and standardized regression coefficients. See details below.

n.iter

Number of iterations per chain (including burnin samples). See run.jags for details.

n.adapt

n.burnin

Number of samples for burnin (samples will not be stored and removed from n.iter)

n.thin

Thinning rate.

n.chains

number of MCMC chains (sampled in parallel).

dic

ppp

number of samples to compute posterior predictive p-value (see posteriorPredictive)

monitorIndividual

whether to store MCMC samples of the MPT parameters theta at the individual level (i.e., the random effects). If FALSE, it is not possible to perform posterior-predictive checks.

modelfilename

name of the generated JAGS model file. Default is to write this information to the tempdir as required by CRAN standards.

parEstFile

Name of the file to with the estimates should be stored (e.g., "parEstFile.txt")

posteriorFile

path to RData-file where to save the model including MCMC posterior samples (an object named fittedModel; e.g., posteriorFile="mcmc.RData")

autojags

...

Value

a list of the class traitMPT with the objects:

summary: MPT tailored summary. Use summary(fittedModel)
mptInfo: info about MPT model (eqn and data file etc.)
mcmc: the object returned from the MCMC sampler. Note that the object fittedModel$mcmc is an runjags object, whereas fittedModel$mcmc$mcmc is an mcmc.list as used by the coda package (mcmc)

Regression Extensions

Continuous and discrete predictors are added on the latent-probit scale via:

\theta = \Phi(\mu + X \beta +\delta ),

where X is a design matrix includes centered continuous covariates and recoded factor variables (using the orthogonal contrast coding scheme by Rouder et al., 2012). Note that both centering and recoding is done internally. TreeBUGS reports unstandardized regression coefficients \beta that correspond to the scale/SD of the predictor variables. Hence, slope estimates will be very small if the covariate has a large variance. TreeBUGS also reports standardized slope parameters (labeled with std) which are standardized both with respect to the variance of the predictor variables and the variance in the individual MPT parameters. If a single predictor variable is included, the standardized slope can be interpreted as a correlation coefficient (Jobst et al., 2020).

For continuous predictor variables, the default prior IVprec = "dgamma(.5,.5)" implies a Cauchy prior on the \beta parameters (standardized with respect to the variance of the predictor variables). This prior is similar to the Jeffreys-Zellner-Siow (JZS) prior with scale parameter s=1 (for details, see: Rouder et. al, 2012; Rouder & Morey, 2012). In contrast to the JZS prior for standard linear regression by Rouder & Morey (2012), TreeBUGS implements a latent-probit regression where the prior on the coefficients \beta is only standardized/scaled with respect to the continuous predictor variables but not with respect to the residual variance (since this is not a parameter in probit regression). If small effects are expected, smaller scale values s can be used by changing the default to IVprec = 'dgamma(.5, .5*s^2)' (by plugging in a specific number for s). To use a standard-normal instead of a Cauchy prior distribution, use IVprec = 'dcat(1)'. Bayes factors for slope parameters of continuous predictors can be computed with the function BayesFactorSlope.

Uncorrelated Latent-Trait Values

The standard latent-trait MPT model assumes a multivariate normal distribution of the latent-trait values, where the covariance matrix follows a scaled-inverse Wishart distribution. As an alternative, the parameters can be assumed to be independent (this is equivalent to a diagonal covariance matrix). If the assumption of uncorrelated parameters is justified, such a simplified model has less parameters and is more parsimonious, which in turn might result in more robust estimation and more precise parameter estimates.

This alternative method can be fitted in TreeBUGS (but not all of the features of TreeBUGS might be compatible with this alternative model structure). To fit the model, the scale matrix V is set to NA (V is only relevant for the multivariate Wishart prior) and the prior on xi is changed: traitMPT(..., V=NA, xi="dnorm(0,1)"). The model assumes that the latent-trait values \delta_i (=random-intercepts) are decomposed by the scaling parameter \xi and the raw deviation \epsilon_i (cf. Gelman, 2006):

\delta_i = \xi \cdot \epsilon_i

\epsilon_i \sim Normal(0,\sigma^2)

\sigma^2 \sim Inverse-\chi^2(df)

Note that the default prior for \xi should be changed to xi="dnorm(0,1)", which results in a half-Cauchy prior (Gelman, 2006).

Author(s)

Daniel W. Heck, Denis Arnold, Nina R. Arnold

References

Gelman, A. (2006). Prior distributions for variance parameters in hierarchical models (comment on article by Browne and Draper). Bayesian Analysis, 1, 515-534.

Jobst, L. J., Heck, D. W., & Moshagen, M. (2020). A comparison of correlation and regression approaches for multinomial processing tree models. Journal of Mathematical Psychology, 98, 102400. doi:10.1016/j.jmp.2020.102400

Klauer, K. C. (2010). Hierarchical multinomial processing tree models: A latent-trait approach. Psychometrika, 75, 70-98. doi:10.1007/s11336-009-9141-0

Rouder, J. N., Morey, R. D., Speckman, P. L., & Province, J. M. (2012). Default Bayes factors for ANOVA designs. Journal of Mathematical Psychology, 56, 356-374. doi:10.1016/j.jmp.2012.08.001

Rouder, J. N., & Morey, R. D. (2012). Default Bayes Factors for Model Selection in Regression. Multivariate Behavioral Research, 47, 877-903. doi:10.1080/00273171.2012.734737

Examples

## Not run:
# fit beta-MPT model for encoding condition (see ?arnold2013):
EQNfile <- system.file("MPTmodels/2htsm.eqn", package = "TreeBUGS")
d.encoding <- subset(arnold2013, group == "encoding", select = -(1:4))
fit <- traitMPT(EQNfile, d.encoding,
  n.thin = 5,
  restrictions = list("D1=D2=D3", "d1=d2", "a=g")
)
# convergence
plot(fit, parameter = "mean", type = "default")
summary(fit)

## End(Not run)

Get Transformed Parameters

Description

Computes transformations of MPT parameters based on the MCMC posterior samples (e.g., differences of parameters).

Usage

transformedParameters(
  fittedModel,
  transformedParameters,
  level = "group",
  nCPU = 4
)

Arguments

fittedModel

either a fitted latent-trait or beta MPT model (traitMPT, betaMPT) or an mcmc.list.

transformedParameters

list with parameter transformations that should be computed based on the posterior samples (e.g., for testing parameter differences: list("diffD=Do-Dn")).

level

whether to compute transformations of "group" or "individual" estimates

nCPU

number of CPU cores across which the MCMC chains are distributed

Value

an mcmc.list of posterior samples for the transformed parameters

Examples

## Not run:
tt <- transformedParameters(fittedModel,
  list("diff = a-b", "p = a>b"),
  level = "individual"
)
summary(tt)

## End(Not run)

Generate EQN Files for Within-Subject Designs

Description

Replicates an MPT model multiple times with different tree, category, and parameter labels for within-subject factorial designs.

Usage

withinSubjectEQN(eqnfile, labels, constant, save)

Arguments

eqnfile

labels

a character vector defining the labels that are added to the parameters in each within-subject condition

constant

optional: a character vector defining which parameters are constrained to be constant across within-conditions

save

optional: path to an EQN output file. By default, the model is return as a string character

Examples

# Example: Standard Two-High-Threshold Model (2HTM)
EQNfile <- system.file("MPTmodels/2htm.eqn",
  package = "TreeBUGS"
)
withinSubjectEQN(EQNfile, c("high", "low"), constant = c("g"))

TreeBUGS: Hierarchical Multinomial Processing Tree Modeling

Description

Citation

Tutorial

Author(s)

References

See Also

Bayes Factors for Simple (Nonhierarchical) MPT Models

Description

Usage

Arguments

Details

References

See Also

Bayes Factor for Slope Parameters in Latent-Trait MPT

Description

Usage

Arguments

Details

References

Examples

Compute Posterior Predictive P-Values

Description

Usage

Arguments

Author(s)

References

WAIC: Widely Applicable Information Criterion

Description

Usage

Arguments

Details

Value

References

Examples

Data of a Source-Monitoring Experiment

Description

Usage

Format

Details

References

Examples

Fit a Hierarchical Beta-MPT Model

Description

Usage

Arguments

Details

Value

Author(s)

References

Examples

C++ Sampler for Hierarchical Beta-MPT Model

Description

Usage

Arguments

Author(s)

Examples

Between-Subject Comparison of Parameters

Description

Usage

Arguments

Value

Author(s)

Posterior Distribution for Correlations

Description

Usage

Arguments

Details

Author(s)

References

Examples

Extend MCMC Sampling for MPT Model

Description

Usage

Arguments

Generate Data for Beta MPT Models

Description

Usage

Arguments

Details
